Compiling

This page provides a simple example of how to use a codemagic.yaml file to compile Godot export templates on a Codemagic build machine. It can also serve as a template for compiling the Godot Editor. We will not discuss how to write a codemagic.yaml file or what are the rules related to this file.

• To learn how codemagic.yaml files work, see Creating codemagic.yaml.

Image by Codemagic, used under CC BY-ND 4.0 license. See gallery

Requirements

To better understand what is done on this page, refers to the following articles:

• Getting Godot source code
• Introduction to build system
• Compiling with Script Encryption Key
• Exporting for Android.
• Compiling for Android

Python, Android SDK, Gradle, Java and some other tools required for Godot compilation are pre-installed on all Codemagic machines. Any additional tools or software required have to be downloaded to the build machine.

• For a complete list of tools and software pre-installed on Codemagic construction machines, go to Integration.
• Additionnaly consult the full list of other pre-installed tools on the build machine we'll use in Other pre-installed tolls on macOS

Sample Script

Godot v4.4.1-stable:

workflows:
  android-export-templates-workflow:
    name: Compiling Android Export templates
    max_build_duration: 120
    instance_type: mac_mini_m2
    working_directory: /Users/builder/Downloads

    environment:
      vars:
        GODOT_BRANCH: 4.4.1-stable
        FILE_COLLECTION_DIRECTORY: /Users/builder/Downloads/templates

    scripts:
      - name: Setting Up
        script: |
          mkdir -p $FILE_COLLECTION_DIRECTORY

          git clone https://github.com/godotengine/godot.git -b $GODOT_BRANCH
          export SOURCE_CODE_DIRECTORY=$(pwd)/godot
          echo "BUILD_DIRECTORY=$SOURCE_CODE_DIRECTORY" >> $CM_ENV
          echo "BUILD_RESULT_DIRECTORY=$SOURCE_CODE_DIRECTORY/bin" >> $CM_ENV
          echo "ANDROID_HOME=$ANDROID_SDK_ROOT" >> $CM_ENV

          cd $SOURCE_CODE_DIRECTORY
          pip install scons
          scons platform=list

      - name: Compiling
        script: |
          cd $BUILD_DIRECTORY
          export SCRIPT_AES256_ENCRYPTION_KEY="aeb1bc56aaf580cc31784e9c41551e9ed976ecba10d315db591e749f3f64890f"
          scons platform=android target=template_release arch=arm32
          scons platform=android target=template_release arch=arm64
          scons platform=android target=template_release arch=x86_32
          scons platform=android target=template_release arch=x86_64 generate_apk=yes

      - name: Files Gathering
        script: zip -r $FILE_COLLECTION_DIRECTORY/export_templates.zip $BUILD_RESULT_DIRECTORY

    artifacts:
      - $FILE_COLLECTION_DIRECTORY/*.zip

Explanations

This script first clones the Godot source code for the given GODOT_BRANCH and installs scons to compile the export templates.
It then displays all available platforms for which scons can compile on the build machine (scons platform=list).
Finally, the script compiles the Android export templates using an encryption key for all Android platforms.
Once compiled successfully, you can download the export templates as a zip file.

Here is a description of the variables used:

Variable name	Description
GODOT_BRANCH	The Git branch of Godot to be cloned for compilation
FILE_COLLECTION_DIRECTORY	The directory in which the zip containing the export templates will be stored
SOURCE_CODE_DIRECTORY	The directory in which Godot's source code is located
BUILD_DIRECTORY	The directory used to launch compilation (identical to SOURCE_CODE_DIRECTORY)
BUILD_RESULT_DIRECTORY	The directory in which compiled models will be stored after compilation
SCRIPT_AES256_ENCRYPTION_KEY	The AES- 256 encryption key to be stored in export templates.

You can now Download configuration file.

Caution!!!

To use this script effectively, consult its Requirements.
This script is based on a specific configuration and may not match your configuration.
